Slide Switch
YSS-19
Single pole; double throws
◆ APPLICATIONS
1. Sub-miniature slide switch with double throws
2.Soldering terminal, option of housings
— FULL SPECIFICATION
Technical data
Electrical
Rated Voltage/Current
(T55) 2A125VAC; 1A250VAC
(T125μ) 2A125VAC; 1A250VAC
Contact Configuration
SPDT
Electrical Life
6000 cycles
Max Switching Current
Max Switching Voltage
Pull-in Value
Min Breakdown Voltage
Mechanical
Overall Dimensions (LxWxH)
9.8*8.2*12.3
Actuator Type
Terminal Type
Terminal type: S,W
Travel Distance
2.2mm
Mechanical Life Cycle
100,000 cycles
Operate Time
Release Time
Environmental
Operating Temperature
0℃ - 85℃
IP Rating
rv
Certifications
Certifications
UL, ETL, TUV, CE/CB, CQC
